Clear your driveway, open up trails, and keep winter chores from slowing you down with the Denali Pro UTV Snow Plow Kit for the 2017+ Yamaha YXZ 1000R. Its curved, 19-inch-scoop blade is designed to roll snow forward, while reinforced steel supports and a heavy-duty wear bar help it handle demanding snow-clearing jobs. With 10 blade-angle positions, adjustable skid feet and quick-detach push tubes, you can adapt to changing conditions and remove the plow when the work is done.
Built for serious winter use, this complete kit includes the blade, push tubes, plow mount, wear bar, skid feet, rubber flap, plow flags and installation hardware. The 1/4-inch steel mount adds a rugged foundation for your YXZ 1000R. Gear up for winter and get more done with Denali at Cheetah’s Powersports.
Kit Includes:
- UTV Snow Plow Blade - Pro Curved
- Pushtubes
- Wearbar
- Skid Feet
- Rubber Flap
- Plow Flags
- Installation hardware and instructions
Plow Mount Features:
- 1/4" steel
- 100% laser cut
- Black, industrial powder coat finish
- Includes mounting hardware and detailed instructions
Blade Features:
- Snow Plow Blade (19-inch scoop) and leading horizontal supports are formed from a single piece of 12-gauge steel
- Four 7-gauge ribs run the full height of the blade
- Three additional 7-gauge horizontal stabilizers support the deepest point of the blade
- 65-degree attack angle and over center design ensures snow rolls up and is thrown forward
- Replaceable 7-gauge steel wear bar included with every kit
- Height and angle adjustable skid feet included
Push Tube Features:
- Impact Resistant Reinforced Pivot Assembly - 2 additional support bars for maximum durability & strength
- Turn system allows you to easily position your plow in 10 different angles - 0, 12.5, 25
- Simple detachment system with the pull of a pin
- Structural tube steel cross bar for added lateral rigidity
- Quick Release Pins included
- 13.5 inches center to center for plow mount tabs
- Extended Push Tubes are designed to be used with SxS/UTVs that have tracks
Pushtube Lift Kits:
- Push tube Lift Kits bolt directly to the pushtubes, providing 2 or 4 inches of lift
- Pushtube Lift Kits allow plow installation on machines with skid plates, 13"-15" and 15"-17" off the ground
- Lift Kits are for use with DENALI UTV Standard Pushtubes only (not Extended Pushtubes)
Optional Hydroturn Features:
- Hydraulic system is sealed, no need to purchase hydraulic fluid, bleed lines, maintain a reservoir level or change the fluid
- Change the blade angle with ease without leaving your seat
- Heavy duty chrome plated 3/4" cylinder shaft
- No modifications necessary - bolts directly to the Denali UTV Plow Push Tubes
- Wire harness utilizes weatherproof connectors
Optional Plow Pulley Fairlead Features:
- Roller
- Replaces the winch fairlead during the plow season
- For use with Steel AND Synthetic cables
- Curved cable groove helps eliminate flattening and breaking of cable
- Bolt Patterns:
- Standard Spool: 3″ x 4.875″
- Wide Spool: 3″ x 6.67″
- Sheave
- Includes pulley, 1/4″ clevis hook and nylon strap
- Allows greater precision when raising/lowering plow blade and increases the angle of pull
- Cable
- 12′ length, 1/4″ diameter
- Single braid, dyneema rope with galvanized steel thimble/eyelet
- All the DENALI Plow Systems require a winch (not included) to raise and lower the plow blade.
